12V EKG/ECG Lithium Battery

No

Items

1

Model:

18650-2000mah

2

Material:

LiNiCoMnO2

3

Nominal Volt:

12V

4

Nominal Capacity:

4400mAh

5

N.W

350g

6

Dimension:

240*95*26.7mm

7

Max. charge volt:

12.6V

8

Discharge cut-off volt:

8.25V

9

Charge method

CC-CV

10

Inner Resistance

180mΩ

11

Continuous discharge current

2A

12

Max. discharge current

4-5 A

13

Applications

EKG, ECG, Diagnostic equipment

14

Working Charge Temp :

0~50°C

15

Working Discharge Temp:

–20°C~60°C

16

Storage Temperature:

–20°C~65°C

17

Cycle life:

500 cycles to 80%

with 100% DOD under normal temperature
